Connector & ports
Internal I/O Ports	1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x CPU fan/water cooling pump header 4 x system fan headers 2 x system fan/water cooling pump headers 3 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 5 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support 1 x USB Type-C® port (DisplayPort), with USB 2.0 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x noise detection header 2 x Thunderbolt™ add-in card connectors 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/ GC-TPM2.0 SPI V2 module only) 1 x Q-Flash Plus button 1 x reset button 1 x reset jumper 2 x temperature sensor headers 1 x Clear CMOS jumper
Connector & ports
LAN Port (s)	Realtek 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps)
Default
Basic Information	Supported CPU:LGA1700 socket: Support for the 14th,13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors L3 cache varies with CPU
Connector & ports	USB (s):Chipset: - 2 x USB Type-C® ports, with USB 3.2 Gen 2x2 support (1 port on the back panel, 1 port available through the internal USB header) - 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support - 1 x USB Type-C® port onboard, with USB 2.0 support - 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel - 2 x USB 3.2 Gen 1 ports available through the internal USB header - 2 x USB 2.0/1.1 ports on the back panel Chipset+USB 3.2 Gen 1 Hub: - 4 x USB 3.2 Gen 1 ports on the back panel Chipset+USB 2.0 Hub:, Supported Storage:CPU: - 1 x M.2 connector (Socket 3, M key, type 25110/2580 PCIe 5.0 x4/x2 SSD support) (M2C_CPU) - 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)Chipset: - 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB) - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) - 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB) - 4 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Generel information
Bundled Software	Norton® Internet Security (OEM version) LAN bandwidth management software
Expansion Slots	PCI:CPU: - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) The PCIEX16 slot operates at up to x8 mode when a device is installed in the M2C_CPU connector. Chipset: - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4_1) - 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4_2)
Operating System	Support for Windows 11 64-bit
Slots	4 x DIMM
Special Features	Support for GIGABYTE Control Center (GCC) Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup
Type	DDR5
Graphics Specifications
Graphics	Graphics:Integrated Graphics Processor-Intel® HD Graphics support: - 1 x USB Type-C® port, supporting USB 3.2 Gen 2 and DisplayPort video outputs and a maximum resolution of 4096x2304@60 Hz - 1 x USB Type-C® port, supporting USB 2.0 and DisplayPort video outputs and a maximum resolution of 1920x1080@30 Hz - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
Main Features
Audio	Realtek® ALC1220-VB CODEC High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset	Intel Z790 Express Chipset
Form Factor	ATX Form Factor; 30.5cm x 24.4cm
Memory Specifications
Supported Memory	Support for DDR5 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules

GIGABYTE Z790 AORUS PRO X 14th,13th And 12th Gen DDR5 Motherboard

The GIGABYTE Z790 AORUS PRO X 14th,13th and 12th Gen DDR5 motherboard is a high-performance and feature-rich platform designed for enthusiasts, gamers, and professionals who demand cutting-edge technology and exceptional versatility for their computing needs. This motherboard, built around the LGA1700 socket, supports both 14th,13thand 12th Generation Intel Core processors, providing an extensive range of options for users.The heart of this motherboard is the Intel Z790 Express Chipset, which ensures rapid data transfer and seamless operation. It features a 256 Mbit flash BIOS with licensed AMI UEFI BIOS, supporting modern standards like ACPI 5.0, DMI 2.7, and more for an optimal user experience.When it comes to audio, the motherboard is equipped with the Realtek ALC1220-VB CODEC, delivering high-definition audio with support for various audio configurations, including 2/4/5.1/7.1-channel setups. Additionally, S/PDIF Out support provides high-quality digital audio output.The motherboard's DDR5 memory support is impressive, allowing for overclocked memory speeds up to 8266 MHz. With four DIMM slots and a maximum memory capacity of 192 GB, this motherboard caters to users who require substantial memory resources for tasks such as content creation, gaming, and more.In terms of expansion, the motherboard offers multiple PCIe slots, including a PCIe 5.0 x16 slot for high-speed graphics cards and two PCIe 4.0 x4 slots for additional expansion cards. The ATX form factor ensures compatibility with a wide range of PC cases, allowing for diverse build options.Connectivity is a strong point of the Z790 AORUS PRO X. It features a wealth of USB ports, including USB Type-C with USB 3.2 Gen 2x2 support, and 5GbE LAN via the Realtek chip. The motherboard supports RAID configurations for both NVMe SSDs and SATA storage devices, providing data redundancy and performance enhancement options.The motherboard includes numerous internal and external connectors for system expansion, including RGB LED headers, SATA ports, USB headers, and more, offering great flexibility for custom PC builds.Special features such as GIGABYTE Control Center, Q-Flash, Q-Flash Plus, and Smart Backup simplify system management and updates. Furthermore, the motherboard comes bundled with Norton Internet Security for added system security.

In summary, the GIGABYTE Z790 AORUS PRO X motherboard is a powerful and versatile platform tailored for enthusiasts, gamers, and professionals. With support for DDR5 memory, high-quality audio, and a plethora of connectivity options, it provides the foundation for a robust and efficient PC build that meets the demands of modern computing tasks, making it a top choice for those who seek high-end performance and flexibility in their systems.

Features:

Supports Intel® Core™ 14th,13th and 12th processors
Digital twin 18+1+2 phases VRM solution
Dual Channel DDR5：4*DIMMs with XMP 3.0 memory module support
PCIe UD Slot X： PCIe 5.0 x16 slot with 10X strength for graphics card
EZ-Latch Click：M.2 heatsinks with screwless design
EZ-Latch Plus：M.2 slots with quick release design
Sensor Panel Link：Onboard video port for hassle-free in-chassis panel setup
UC BIOS：User-Centred intuitive UX with Quick Access function
Ultra-Fast Storage：5*M.2 slots, including 1* PCIe 5.0 x4
Efficient Overall Thermal：VRM Thermal Armor Advanced & M.2 Thermal Guard XL
Fast Networking：5GbE LAN & Wi-Fi 7 with Ultra-high gain antenna
Extended Connectivity：HDMI, DP IN, Front & Rear USB-C® 20Gb/s
High-Res Audio：ALC1220 & Audiophile Grade Capacitors

GIGABYTE Z790 AORUS PRO X Price in BD

X marks the 14th generation! Introducing the AORUS Z790 X Gen Motherboards, the most powerful platforms ever built for the Intel® Core™ 14th Gen processors. With the leading performance in DDR5 memory, the upgraded DIY-friendly innovations, and the all-new BIOS redesigned as user-centered, the AORUS Z790 X Gen Motherboards are built to fully unleash the next-gen power.

GIGABYTE Z790 AORUS PRO X Review:

The GIGABYTE Z790 AORUS PRO X motherboard offers a formidable platform for 1th and 12th Generation Intel Core processors. Its DDR5 memory support, overclockable up to 8266 MHz, and 192 GB maximum capacity cater to power users, while the Intel Z790 Express Chipset ensures high-speed data transfer. The Realtek ALC1220-VB audio and versatile graphics options provide an immersive multimedia experience. An abundance of USB ports, 5GbE LAN, and support for RAID configurations make it a connectivity powerhouse. With a host of special features and bundled Norton Internet Security, this motherboard is a compelling choice for those seeking performance and versatility in their PC builds.
