Name: Gigabyte A520M S2H Ultra Durable AMD AM4 ATX Motherboard
Brand: Gigabyte
Price: 9500.00 BDT
Availability: InStock

Gigabyte A520M S2H Ultra Durable AMD AM4 ATX Motherboard

Gigabyte A520M S2H Ultra Durable AMD AM4 ATX Motherboard

Status: In Stock
Brand: Gigabyte
Model: A520M S2H Ultra Durable

Based on 0 reviews. - Write a review

9,500৳

Ex Tax: 9,500৳

Qty

Add to Cart

Buy Now Question

Add to Wish List Compare this Product

Key Features

Price Change Declaimer

AVA Technology can change The price of any product at any moment due to the volatile price of the technology product.

Payment Options

Visa & Mastercard.

Mobile Banking ~~(5 banks)~~

Internet Banking ~~(10 Banks)~~

Cash Payment

Product Image Declaimer

Product Image For Illustration Purposes Only. Actual Product May Vary In Size, Color, And Layout. No Claim Will Be Accepted For Image Mismatch

Product Information Declaimer

We cannot guarantee that the information on this page is 100% correct. AVA Technology is not liable for usage outcomes.

Connector & ports
LAN Port (s)	Realtek GbE LAN chip (1000 Mbit/100 Mbit)
Connector & ports
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x serial port header 1 x speaker header 1 x chassis intrusion header 1 x Clear CMOS jumper
Default
Ports, Connectors & Slots	USB (s):CPU: 4 x USB 3.2 Gen 1 ports on the back panel Chipset: 2 x USB 3.2 Gen 1 ports available through the internal USB header 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers), Supported Storage:CPU: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support) Chipset: 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, and RAID 10
Generel information
D-Sub (s)	1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
DVI-D (s)	1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
Expansion Slots	PCI:CPU: 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16Chipset: 2 x PCI Express x1 slots, supporting PCIe 3.0
M.2 Socket	1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
Manufacturing Warranty	03 years
Memory	Supported Memory:3rd Gen AMD Ryzen Processors: Support for DDR4 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules 3rd Gen AMD Ryzen with Radeon Graphics processors: Support for DDR4 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
Slots	2 x DDR4 DIMM
Special Features	Support for APP Center @BIOS EasyTune Fast Boot Game Boost ON/OFF Charge RGB Fusion Smart Backup System Information Viewer Support for Q-Flash Plus Support for Q-Flash Support for Xpress Install Support for Q-Flash Support for Xpress Install
TPM (Trusted Platform Module )	1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
Type	Dual channel memory architecture
Graphics Specifications
Graphics	Graphics:Integrated in the 3rd Generation AMD Ryzen with Radeon Graphics processors: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
Max Shared Memory	16 GB
Main Features
Audio	Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel
BIOS	1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset	AMD A520
Form Factor	Micro ATX Form Factor; 24.4cm x 20.5cm
Supported CPU	AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
Memory Specifications
Maximum Memory	64 GB
Ports, Connectors & Slots
HDMI/VGA	1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

Gigabyte A520M S2H Ultra Durable AMD AM4 ATX Motherboard

Gigabyte A520M S2H Ultra Durable motherboard is a reliable and feature-rich solution designed for compatibility with AMD Ryzen 5000/4000G Series and 3rd Generation processors. Featuring the AMD A520 chipset, this Micro ATX motherboard offers a balance between performance and value.With a focus on expandability, the motherboard provides a range of connectivity options, including 1 x PCI Express x16 slot for dedicated graphics cards and 2 x PCI Express x1 slots. It also features a versatile M.2 socket that supports both SATA and PCIe 3.0 x4/x2 SSDs, enhancing storage performance.Memory-wise, the motherboard supports up to 64 GB of DDR4 RAM in dual-channel configuration, catering to the demands of modern applications and multitasking.The integrated graphics capabilities of 3rd Generation AMD Ryzen processors with Radeon Graphics are fully harnessed through ports like D-Sub, DVI-D, and HDMI, supporting resolutions up to 4096x2160@60 Hz. The Realtek ALC887 codec ensures high-definition audio output for 2/4/5.1/7.1-channel setups.For internal components, the motherboard offers a comprehensive array of connectivity options, including USB 3.2 Gen 1 and USB 2.0/1.1 headers, SATA 6Gb/s connectors for storage devices, and various system fan and LED strip headers for customization.The Gigabyte A520M S2H is equipped with an array of software utilities like APP Center, @BIOS, EasyTune, and RGB Fusion for system optimization, customization, and control. The inclusion of Q-Flash Plus, Smart Backup, and System Information Viewer further enhances its functionality and user experience.With its Micro ATX form factor measuring 24.4cm x 20.5cm, the motherboard strikes a balance between compactness and expandability, making it suitable for various system builds. Backed by a 3-year manufacturing warranty, the Gigabyte A520M S2H Ultra Durable motherboard offers a solid foundation for building reliable and versatile AMD-based systems.

Gigabyte A520M S2H Ultra Durable AMD AM4 ATX Motherboard Features:

CPU Compatibility: Supports AMD Ryzen 5000/4000G Series and 3rd Generation processors for powerful computing performance.
Chipset: Equipped with the AMD A520 chipset for reliable and efficient system operation.
Expansion Slots: Features 1 x PCI Express x16 slot (PCIe 3.0 x16), and 2 x PCI Express x1 slots for versatile expansion options.
Memory: Dual-channel architecture with support for up to 64 GB of DDR4 memory at various speeds, enhancing multitasking capabilities.
Integrated Graphics: Comes with integrated graphics support for 3rd Generation AMD Ryzen processors with Radeon Graphics, featuring D-Sub, DVI-D, and HDMI outputs.
M.2 Socket: Includes 1 x M.2 connector supporting M key type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSDs, improving storage performance.
Connectivity: Provides Realtek GbE LAN chip (1000 Mbit/100 Mbit) for reliable networking.
Audio: Incorporates Realtek ALC887 codec for high-definition audio output with support for 2/4/5.1/7.1-channel setups.
USB Ports: Features a variety of USB ports, including 4 x USB 3.2 Gen 1 ports on the back panel and additional USB 3.2 Gen 1 and USB 2.0/1.1 headers.
SATA Connectors: Offers 4 x SATA 6Gb/s connectors for connecting storage devices, supporting RAID 0, RAID 1, and RAID 10 configurations.
TPM Header: Includes a Trusted Platform Module (TPM) header for enhanced system security.
Internal I/O Ports: Provides a range of internal connectors, including CPU and system fan headers, addressable and RGB LED strip headers, and more.
Special Features: Offers various utilities such as APP Center, @BIOS, EasyTune, Fast Boot, Game Boost, ON/OFF Charge, RGB Fusion, Smart Backup, and System Information Viewer for system optimization and control.
Form Factor: Micro ATX form factor (24.4cm x 20.5cm) strikes a balance between compactness and expandability.
Warranty: Backed by a 3-year manufacturing warranty, ensuring peace of mind for buyers.

Summary Of Gigabyte A520M S2H Ultra Durable AMD AM4 ATX Motherboard

The Gigabyte A520M S2H Ultra Durable Micro ATX motherboard is built for AMD Ryzen 5000/4000G Series and 3rd Generation processors, featuring an AMD A520 chipset. With support for up to 64 GB of DDR4 memory, it offers a dual-channel architecture and integrated graphics outputs including D-Sub, DVI-D, and HDMI. It boasts expansion options like PCIe x16, M.2 socket for SATA and PCIe SSDs, and PCIe x1 slots. Additional features encompass Realtek ALC887 audio, Realtek GbE LAN, USB 3.2 Gen 1, USB 2.0/1.1 ports, SATA 6Gb/s connectors with RAID support, and TPM header. The board includes software utilities and comes with a 3-year warranty.
