Name: GIGABYTE A520M DS3H AC Ultra Durable AM4 Micro-ATX Motherboard
Brand: Gigabyte
Price: 12500.00 BDT
Availability: InStock

GIGABYTE A520M DS3H AC Ultra Durable AM4 Micro-ATX Motherboard

GIGABYTE A520M DS3H AC Ultra Durable AM4 Micro-ATX Motherboard

Status: In Stock
Brand: Gigabyte
Model: A520M DS3H AC Ultra Durable AM4 Micro-ATX

Based on 0 reviews. - Write a review

12,500৳

Ex Tax: 12,500৳

Qty

Add to Cart

Buy Now Question

Add to Wish List Compare this Product

Key Features

Price Change Declaimer

AVA Technology can change The price of any product at any moment due to the volatile price of the technology product.

Payment Options

Visa & Mastercard.

Mobile Banking ~~(5 banks)~~

Internet Banking ~~(10 Banks)~~

Cash Payment

Product Image Declaimer

Product Image For Illustration Purposes Only. Actual Product May Vary In Size, Color, And Layout. No Claim Will Be Accepted For Image Mismatch

Product Information Declaimer

We cannot guarantee that the information on this page is 100% correct. AVA Technology is not liable for usage outcomes.

Connector & ports
LAN Port (s)	Realtek GbE LAN chip (1000 Mbit/100 Mbit)
Connector & ports
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x serial port header 1 x Clear CMOS jumper 1 x Q-Flash Plus button
Connector & ports
HDMI	1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
Default
Connector & ports	USB (s):4 x USB 3.2 Gen 1 ports on the back panel Chipset: 2 x USB 3.2 Gen 1 ports available through the internal USB header 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header), Supported Storage:CPU: 1 x M.2 connector (Socket 3, M key, type 2242/ 2260/ 2280 SATA and PCIe 3.0 x4/ x2 SSD support) Chipset: 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, and RAID 10
Generel information	PCI:CPU: 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 Chipset: 2 x PCI Express x1 slots, supporting PCIe 3.0 (PCIEX1_1, PCIEX1_2)
Main Features	Supported CPU:AMD Socket AM4, support for: AMD Ryzen 5000 Series/ 3rd Gen Ryzen and 3rd Gen Ryzen with
Memory Specifications	Supported Memory:AMD Ryzen 5000 series processors/ 3rd Generation AMD Ryzen: Support for 4400(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules3rd Gen AMD Ryzen with Radeon Graphics processors: Support for 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/ 2Rx8 memory modules Support for non-ECC Un-buffered DIMM 1Rx8/ 2Rx8/ 1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules
Generel information
AUDIO CODEC	Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel
Display Port (s)	1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz
DVI-D (s)	1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
M.2 Socket	1 x M.2 connector (Socket 3, M key, type 2242/ 2260/ 2280 SATA and PCIe 3.0 x4/x2 SSD support)
Manufacturing Warranty	3 Years
Slots	4 x DIMM sockets
Special Features	Support for APP Center @BIOS EasyTune Fast Boot Game Boost ON/OFF Charge RGB Fusion Smart Backup System Information Viewer Support for Q-Flash Plus Support for Q-Flash Support for Xpress Install
TPM (Trusted Platform Module )	1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
Type	DDR4
Wireless Communication module	Intel Wi-Fi 3168 WIFI 802.11a/b/g/n/ac, supporting 2.4/ 5 GHz Dual-Band BLUETOOTH 4.2 Support for 11ac wireless standard and up to 433 Mbps data rate
Graphics Specifications
Max Shared Memory	16 GB
Main Features
BIOS	1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset	AMD A520
Form Factor	Micro ATX Form Factor; 24.4cm x 24.4cm
Memory Specifications
Maximum Memory	128 GB (32 GB single DIMM capacity)

GIGABYTE A520M DS3H AC Ultra Durable AM4 Micro-ATX Motherboard

The GIGABYTE A520M DS3H AC is a high-quality, ultra-durable motherboard designed for use with AMD AM4 processors. It features an ultra-fast PCIe 3.0 x16 slot for high-speed graphics cards, two DDR4 DIMM slots for up to 64GB of system memory, and dual M.2 slots for high-speed NVMe SSDs. The motherboard also includes support for AMD StoreMI technology, which combines the speed of an SSD with the capacity of a traditional hard drive to deliver faster boot times, improved system responsiveness, and quicker application load times. In addition, the A520M DS3H AC features high-quality audio with support for 7.1-channel surround sound and a built-in Realtek 8118 LAN chip for reliable, high-speed internet connectivity. The board also has a range of connectivity options, including USB 3.2 Gen 1 and Gen 2 ports, HDMI and DVI video outputs, and PS/2 ports for legacy peripherals. The motherboard also features GIGABYTE's Ultra Durable technology, which includes high-quality components such as solid capacitors, low RDS(on) MOSFETs, and overvoltage protection to ensure stable and reliable performance.

Overall, the GIGABYTE A520M DS3H AC is a high-quality and reliable motherboard that is suitable for a wide range of computing needs, including gaming, home entertainment, and productivity applications.

Features

Here are some of the key features of the GIGABYTE A520M DS3H AC Ultra Durable AM4 Micro-ATX Motherboard:

AMD AM4 Socket: The motherboard is designed to work with the latest AMD Ryzen processors, including the Ryzen 5000 series.
Ultra Durable Technology: The motherboard features GIGABYTE's Ultra Durable technology, which includes high-quality components such as solid capacitors, low RDS(on) MOSFETs, and overvoltage protection to ensure stable and reliable performance.
PCIe 3.0 x16 Slot: The motherboard features an ultra-fast PCIe 3.0 x16 slot for high-speed graphics cards.
Dual M.2 Slots: The motherboard includes dual M.2 slots for high-speed NVMe SSDs, allowing for fast boot and load times.
AMD StoreMI: The motherboard supports AMD StoreMI technology, which combines the speed of an SSD with the capacity of a traditional hard drive to deliver faster boot times, improved system responsiveness, and quicker application load times.
High-Quality Audio: The motherboard features high-quality audio with support for 7.1-channel surround sound, providing a rich and immersive audio experience.
Realtek 8118 LAN Chip: The motherboard includes a built-in Realtek 8118 LAN chip for reliable, high-speed internet connectivity.
Connectivity Options: The motherboard has a range of connectivity options, including USB 3.2 Gen 1 and Gen 2 ports, HDMI and DVI video outputs, and PS/2 ports for legacy peripherals.
Dual DDR4 DIMM Slots: The motherboard includes two DDR4 DIMM slots for up to 64GB of system memory, allowing for fast and efficient multitasking.

Overall, the GIGABYTE A520M DS3H AC Ultra Durable AM4 Micro-ATX Motherboard is a high-quality and reliable motherboard that offers a range of features and connectivity options suitable for a wide range of computing needs.
